Convert MER to PDF

Understanding MER and PDF file formats

MER files are project files created by FactoryTalk View Machine Edition (ME), a software from Rockwell Automation used for developing Human Machine Interface (HMI) applications for industrial automation. These files contain graphics, logic, and configuration data for HMI panels.

PDF (Portable Document Format) is a widely used file format developed by Adobe for presenting documents in a manner independent of application software, hardware, or operating systems. PDF files are ideal for sharing and printing documents while preserving formatting.

Why convert MER to PDF?

Converting a MER file to PDF allows you to share HMI project documentation, screenshots, or configuration details with stakeholders who do not have access to FactoryTalk View ME. PDF files are easy to view, print, and archive.

How to convert MER to PDF

Direct conversion from MER to PDF is not possible because MER files are not document files but project archives. The typical process involves extracting the project contents and exporting relevant screens or documentation to PDF.

1. Restore the MER file in FactoryTalk View Studio using Application Manager to create an editable project.
2. Open the project in FactoryTalk View Studio.
3. Export screens or documentation by taking screenshots or using the built-in reporting tools.
4. Save or print to PDF using File → Print and selecting a PDF printer, or use Export options if available.

Best software for MER to PDF conversion

• FactoryTalk View Studio (Rockwell Automation): Essential for opening and extracting content from MER files.
• PDF printers (such as Adobe PDF or Microsoft Print to PDF): For saving screens or reports as PDF files.
• Snagit or Greenshot: For capturing high-quality screenshots of HMI screens to include in PDFs.

Summary

While there is no direct MER to PDF converter, you can extract and document HMI project information from MER files using FactoryTalk View Studio and then export or print the relevant content to PDF for easy sharing and archiving.
