Convert PRTDOT to DWG

Understanding prtdot and dwg file formats

PRTDOT is a SolidWorks Part Template file used to standardize part creation in SolidWorks, a leading 3D CAD software. It contains predefined settings, properties, and features for new part files. DWG is a widely used AutoCAD Drawing file format developed by Autodesk, primarily for storing 2D and 3D design data and metadata.

Why convert prtdot to dwg?

Converting a prtdot file to dwg format allows you to share your SolidWorks part templates with users of AutoCAD or other CAD software that supports DWG. This is useful for collaboration, documentation, or manufacturing workflows that require DWG files.

How to convert prtdot to dwg

Direct conversion from prtdot to dwg is not possible because prtdot is a template, not an actual part. You must first create a part (SLDPRT) from the template, then export that part to DWG.

1. Open SolidWorks.
2. Go to File → New and select your prtdot template to create a new part.
3. Design or import the geometry you want to export.
4. Go to File → Save As.
5. In the Save as type dropdown, select DWG (*.dwg).
6. Click Save and follow the export options to complete the conversion.

Best software for prtdot to dwg conversion

The most reliable software for this conversion is SolidWorks itself, as it natively supports both prtdot and DWG export. For batch conversions or automation, consider using SolidWorks Task Scheduler or third-party plugins like Autodesk Inventor (after exporting to a compatible format).

Tips and considerations

• Only the geometry and features present in the part will be exported; template settings are not transferred to DWG.
• For 2D drawings, create a drawing from the part and export the drawing to DWG for best results.
• Check exported DWG files in AutoCAD or a DWG viewer to ensure accuracy.
