Understanding DWFX and IGS file formats
DWFX (Design Web Format XPS) is a file format developed by Autodesk for sharing 2D and 3D design data. It is based on the XML Paper Specification (XPS) and is commonly used for viewing and sharing CAD drawings without exposing the original design files.
IGS (Initial Graphics Exchange Specification), also known as IGES, is a neutral file format used for exchanging 2D and 3D CAD data between different CAD systems. It is widely supported in engineering and manufacturing industries for interoperability.
Why convert DWFX to IGS?
Converting a DWFX file to IGS format allows you to transfer design data from Autodesk-based workflows to a wide range of CAD and CAM applications that support IGES. This is essential for collaboration, manufacturing, and further editing in non-Autodesk environments.
How to convert DWFX to IGS
Direct conversion from DWFX to IGS is not commonly supported by most CAD software. The typical workflow involves first converting DWFX to a more widely supported CAD format (such as DWG or DXF), and then exporting to IGS. Here’s how you can do it:
- Open the DWFX file in Autodesk Design Review or Autodesk AutoCAD.
- Export or save as DWG/DXF:
- In Autodesk Design Review: File → Export → DWFx to DWG (if available).
- In AutoCAD: File → Open the DWFX, then File → Save As → DWG or DXF.
- Open the DWG/DXF file in a CAD program that supports IGES export, such as Autodesk AutoCAD, SolidWorks, or FreeCAD.
- Export to IGS/IGES:
- In AutoCAD: File → Export → Other Formats → IGES (*.igs) (requires IGES plugin or add-on).
- In FreeCAD: File → Export → IGES (*.igs).
Best software for DWFX to IGS conversion
- Autodesk AutoCAD: Industry-standard CAD software with support for DWFX, DWG, and IGES (with add-ons).
- FreeCAD: Free and open-source CAD software that can import DWG/DXF (with plugins) and export to IGES.
- SolidWorks: Professional CAD software with robust import/export capabilities, including IGES.
- Online converters: Some online services (e.g., Aconvert) may offer direct conversion, but results may vary and privacy should be considered.
Tips for successful conversion
- Check the integrity of the geometry after each conversion step.
- Use the latest versions of software for best compatibility.
- For complex 3D models, manual checking and cleanup may be required after conversion.
