Convert STEP to X_B

Find a software converter able to convert step files to x_b files.

Convert step to x_b

How to convert step to x_b file

step to x_b conversion pretty much represents conversion of 3D models saved in ISO STEP product data files (.stp, .step) to one of the formats used by Parasolid (.x_b). It should be doable in several CAD programs or even some of the dedicated 3D modeling / conversion programs.

101convert.com Assistant Avatar

101convert.com assistant bot
3mos

Understanding the X_B file format

The X_B file format is a binary file format used by Parasolid, a geometric modeling kernel used in CAD (Computer-Aided Design) software. It is known for its ability to store complex 3D models and is widely used in engineering and manufacturing industries.

Understanding the target file format

Since the target file format is not specified, it is important to identify the desired format for conversion. Common target formats for 3D models include STL, STEP, and IGES, each serving different purposes in 3D modeling and printing.

Steps to convert X_B files

To convert an X_B file to another format, you will need a software tool that supports both the X_B format and your desired target format. Here are the general steps:

  1. Open the CAD software that supports X_B files, such as Siemens NX or Solid Edge.
  2. Use the File menu to Open the X_B file you wish to convert.
  3. Once the file is open, navigate to the File menu again and select Export or Save As.
  4. Choose the desired target format (e.g., STL, STEP, IGES) from the list of available formats.
  5. Click Save or Export to complete the conversion process.

Best software for X_B file conversion

For converting X_B files, Siemens NX and Solid Edge are highly recommended due to their robust support for Parasolid files and a wide range of export options. Additionally, Autodesk Fusion 360 can be used for its user-friendly interface and cloud-based capabilities.
