Convert SAT to SLDDRW

Understanding SAT and SLDDRW file formats

SAT files are 3D model files based on the ACIS solid modeling technology, commonly used for exchanging 3D geometry data between different CAD applications. These files store precise geometric information and are widely supported in engineering and design workflows.

SLDDRW files are drawing files created by SolidWorks, a leading CAD software. SLDDRW files contain 2D drawing sheets, annotations, and views generated from 3D models, and are used for documentation and manufacturing purposes.

How to convert SAT to SLDDRW

Direct conversion from SAT to SLDDRW is not straightforward, as SAT is a 3D model format and SLDDRW is a 2D drawing format. The typical workflow involves importing the SAT file into SolidWorks, creating a 3D part or assembly, and then generating a drawing from that model.

Step-by-step conversion process using SolidWorks

1. Open SolidWorks.
2. Go to File → Open and select your SAT file.
3. SolidWorks will import the 3D geometry. Save the imported model as a SLDPRT (part) or SLDASM (assembly) file.
4. To create a drawing, go to File → Make Drawing from Part/Assembly.
5. Choose a drawing template and insert the desired views of your model.
6. Save the drawing as a SLDDRW file using File → Save As.

Recommended software for SAT to SLDDRW conversion

The best software for this conversion is SolidWorks, as it natively supports both SAT import and SLDDRW creation. Alternative CAD programs may import SAT files, but only SolidWorks can generate native SLDDRW files.

Key considerations

• Ensure your version of SolidWorks supports SAT file import (most recent versions do).
• Check the imported geometry for accuracy before creating the drawing.
• SLDDRW files are only fully compatible with SolidWorks.
