Convert SLDASM to 3DXML

Understanding sldasm and 3dxml file formats

SLDASM is the file extension for SolidWorks Assembly files, which store 3D assembly data, including references to individual part files (SLDPRT), constraints, and relationships. These files are widely used in mechanical design and engineering for assembling multiple components into a single project.

3DXML is a lightweight XML-based 3D file format developed by Dassault Systèmes. It is designed for sharing, viewing, and collaborating on 3D data, especially within the Dassault Systèmes ecosystem, such as CATIA, ENOVIA, and 3DVIA.

Why convert sldasm to 3dxml?

Converting SLDASM to 3DXML is often necessary for interoperability between SolidWorks and Dassault Systèmes applications. This enables seamless sharing, visualization, and collaboration on 3D assemblies across different platforms.

How to convert sldasm to 3dxml

Direct conversion from SLDASM to 3DXML is not natively supported in SolidWorks. However, you can use Dassault Systèmes 3DEXPERIENCE Exchange or CATIA with the appropriate plug-ins. Here’s a common workflow using CATIA:

1. Open your SLDASM file in CATIA (ensure you have the SolidWorks-to-CATIA import add-on).
2. Check the assembly for correct part references and geometry.
3. Go to File → Save As or File → Export.
4. Select 3DXML as the output format.
5. Choose export options as needed and save the file.

Alternatively, 3DEXPERIENCE Exchange can be used for cloud-based conversion if you have access to the platform.

Recommended software for conversion

• CATIA (with SolidWorks import add-on): Best for professional, accurate conversions.
• 3DEXPERIENCE Exchange: Ideal for cloud-based workflows and collaboration.
• SolidWorks (with 3DXML export plug-in, if available): For direct export from SolidWorks.

Tips for successful conversion

• Ensure all referenced SLDPRT files are available and in the correct location.
• Check for feature compatibility between SolidWorks and CATIA to avoid data loss.
• Review the exported 3DXML file in a 3DXML viewer to verify assembly integrity.
