Convert SLDASM to EDRW

Understanding sldasm and edrw file formats

SLDASM is the file extension for SolidWorks Assembly files. These files store 3D assembly data, referencing multiple part files (SLDPRT) and their relationships within a project. EDRW files are eDrawings drawing files, a lightweight, read-only format used for sharing and viewing 2D and 3D CAD data, primarily created with SolidWorks eDrawings Publisher.

Why convert sldasm to edrw?

Converting SLDASM to EDRW allows users to share complex assembly designs in a compact, secure, and easily viewable format. EDRW files are ideal for collaboration, review, and distribution, as they can be opened with the free eDrawings Viewer without exposing proprietary design data.

How to convert sldasm to edrw

The most reliable way to convert SLDASM to EDRW is by using SolidWorks with the eDrawings add-in. Here’s how:

1. Open your SLDASM file in SolidWorks.
2. Go to File → Save As.
3. In the Save as type dropdown, select eDrawings (*.edrw).
4. Click Save to export your assembly as an EDRW file.

Alternatively, you can use the eDrawings Publisher add-in within SolidWorks for more export options, such as password protection or disabling measurement tools.

Best software for sldasm to edrw conversion

• SolidWorks (with eDrawings add-in): The most accurate and feature-rich method.
• eDrawings Professional: Allows direct opening and saving of SLDASM files as EDRW.

Online converters are generally not available for this conversion due to the proprietary nature of SLDASM files and the need for all referenced part files.

Tips for successful conversion

• Ensure all referenced SLDPRT files are accessible and in the correct locations.
• Check the exported EDRW file in eDrawings Viewer to verify accuracy.
• Use export options to control file size, security, and included data.
