Convert BREP to STL

Understanding BREP and STL file formats

BREP (Boundary Representation) is a CAD file format used to describe the geometry and topology of 3D objects with high precision. It stores information about surfaces, edges, and vertices, making it ideal for detailed modeling and engineering applications.

STL (Stereolithography) is a widely used file format for 3D printing and rapid prototyping. It represents 3D models as a collection of triangular facets, making it suitable for manufacturing but less precise than BREP for design modifications.

Why convert BREP to STL?

Converting a BREP file to STL is essential when you need to prepare a CAD model for 3D printing or other mesh-based manufacturing processes. STL files are compatible with most 3D printers and slicing software, while BREP files are not.

How to convert BREP to STL

To convert a BREP file to STL, you need to export or save the model in STL format using CAD software that supports both formats. The process typically involves tessellating the precise BREP geometry into a mesh of triangles.

Recommended software for BREP to STL conversion

• FreeCAD: Open your BREP file, select the object, then use File → Export and choose STL as the file type.
• Autodesk Fusion 360: Import the BREP file, then go to File → Export and select STL as the output format.
• Rhino 3D: Open the BREP file, then use File → Save As and pick STL from the list of formats.

Tips for successful conversion

• Check the mesh resolution settings during export to balance file size and model accuracy.
• Inspect the STL file after conversion to ensure all features are preserved and there are no mesh errors.
• Use software with robust BREP and STL support to avoid data loss or conversion artifacts.

Conclusion

Converting BREP to STL is a straightforward process with the right CAD software. FreeCAD is a highly recommended free tool for this task, offering reliable conversion and mesh control options.
