Convert EDRW to IPT

Understanding edrw and ipt file formats

EDRW is a file extension used for eDrawings, a lightweight, view-only format created by SolidWorks for sharing 2D and 3D CAD data. EDRW files are primarily used for viewing, markup, and collaboration, but they do not contain full model data for editing.

IPT is the file extension for Autodesk Inventor Part files. These files store 3D part models and are fully editable within Autodesk Inventor, supporting parametric modeling and advanced CAD features.

Why convert edrw to ipt?

Converting an EDRW file to an IPT file allows users to edit and further develop the design in Autodesk Inventor. Since EDRW is a view-only format, conversion is necessary for any design modifications or integration into Inventor assemblies.

How to convert edrw to ipt

Direct conversion from EDRW to IPT is not natively supported, as EDRW files lack the full model data required for editing. However, you can use the following workflow:

1. Open the EDRW file in SolidWorks eDrawings or SolidWorks (if you have access to the original SLDPRT or SLDASM file, use that instead).
2. If you only have the EDRW, try to export it as a neutral 3D format such as STEP (.step, .stp) or IGES (.igs, .iges) using File → Save As or File → Export if available.
3. Open Autodesk Inventor and import the exported STEP or IGES file using File → Open and selecting the appropriate file type.
4. Once imported, save the file as an IPT using File → Save As and choosing the IPT format.

Note: If the EDRW file cannot be exported to a 3D format, you may need to request the original SolidWorks part file (SLDPRT) from the file creator.

Best software for edrw to ipt conversion

• SolidWorks: Best for accessing original model data and exporting to neutral formats.
• Autodesk Inventor: Ideal for importing neutral CAD formats and saving as IPT.
• eDrawings Professional: Useful for viewing and limited exporting, depending on file permissions.

Online converters are generally not available for this conversion due to the proprietary nature of EDRW files and the need for full model data.

Summary

While direct EDRW to IPT conversion is not possible, exporting to a neutral CAD format and then importing into Autodesk Inventor is the most effective workflow. Access to the original SolidWorks files will provide the best results.
