Convert DRWDOT to SLDDRT

Understanding drwdot and slddrt file formats

DRWDOT files are SolidWorks Drawing Templates. They store predefined settings, sheet formats, and drawing standards used to create new drawings in SolidWorks. SLDDRT files, on the other hand, are SolidWorks Sheet Format files. These contain the border, title block, and other sheet-specific information, and are referenced by drawing templates.

Why convert drwdot to slddrt?

Converting a DRWDOT to SLDDRT is useful when you want to extract or modify the sheet format (such as borders and title blocks) from an existing drawing template for reuse or customization in other templates or drawings.

How to convert drwdot to slddrt

SolidWorks does not provide a direct export or save-as option to convert a DRWDOT file to SLDDRT. However, you can extract the sheet format from a drawing template using the following steps:

1. Open SolidWorks and go to File → Open, then select your DRWDOT file.
2. Once the template is open, right-click on the drawing sheet and select Properties to ensure the correct sheet is active.
3. Right-click on the sheet again and choose Save Sheet Format.
4. In the dialog, choose a location and save the file as SLDDRT.

This process extracts the sheet format from your template and saves it as a standalone SLDDRT file.

Best software for drwdot to slddrt conversion

The best and most reliable software for this conversion is SolidWorks itself. Third-party converters are not recommended due to the proprietary nature of these formats and the risk of data loss or corruption.

Summary

To convert a DRWDOT file to SLDDRT, use SolidWorks to open the template and save the sheet format. This ensures compatibility and preserves all formatting details.
