A PCB workflow may need a board document for component placement, routing, and manufacturing preparation, even when the design exists only as a schematic. An EAGLE schematic can generate an EAGLE board file, but unrelated CAD schematics cannot be converted by changing the filename extension.
What the sch format contains
In Autodesk EAGLE, .sch stores a circuit schematic: symbols, component values, and electrical connections. EAGLE schematics are normally kept with their matching board file in one project. The extension is used by other CAD applications too, so identify the program that created the file before opening it; an OrCAD schematic is not automatically an EAGLE schematic.
What the brd format contains
In EAGLE, .brd stores the printed-circuit-board layout, including component footprints, placement, board outline, copper routes, and design connectivity. It is an editable CAD document, not a fabrication package; manufacturing commonly requires outputs such as Gerber and drill files. The .brd extension is also used by other PCB systems, and those files are not necessarily interchangeable with EAGLE boards.
Create an eAGLE board from a schematic
- Open or import the EAGLE project in Autodesk Fusion Electronics, which supports EAGLE design files. A compatible installed EAGLE release can also perform this workflow.
- Open the schematic and check that every component has an assigned PCB package (footprint). Components without packages cannot be placed on the board correctly.
- Choose Switch to board (in legacy EAGLE, File → Switch to board). If no board exists, accept the prompt to create one. The schematic components and connections appear in the board editor, generally as unplaced parts joined by airwires.
- Draw or set the board outline, place components, route the connections, and run the design-rule check. Save the resulting board as
.brdalongside its schematic, and keep the two synchronized through the CAD application.
Compatibility and conversion limits
This creates an initial layout, not a finished PCB: a schematic does not specify board dimensions, component placement, or copper routing. Review footprints, clearances, design rules, and connectivity before generating manufacturing files.
If the source .sch belongs to another CAD program, EAGLE or Fusion may not read it as an EAGLE schematic. Use the source application’s supported PCB handoff or export, then map components to footprints and create the board in a compatible PCB tool. OrCAD PSpice Designer is not a general converter to EAGLE .brd; an OrCAD workflow produces a board for its compatible PCB system, not an interchangeable EAGLE file. No generic online converter can infer the missing physical layout, so an online conversion is not a suitable substitute for the CAD workflow.
SCH vs BRD: format comparison
How the SCH and BRD formats compare on the properties that matter most for this conversion.
| Property | .SCH Electronic schematic (EAGLE / KiCad) | .BRD EAGLE PCB board file |
|---|---|---|
| Dimensions | 2D | 2D |
| Layers | — | Yes |
| Materials | No | No |
| Plain-text readable | Yes | — |
| Operating system support | Wide | Limited |
| Typical file size | Small | Small |
| Open standard | Partly open | No |
| Developer | — | Autodesk (originally CadSoft) |
