Convert CATPART to 3DXML

Export CATIA part geometry to 3DXML for lightweight viewing and review.

Popular online conversions: 3D modeling

We don't have an online converter for CATPART to 3DXML yet. Try one of the most used conversions in 3D modeling:

All conversions in 3D modeling →

Want to convert CATPART to 3DXML?

Let us know. We pick the conversions to add next by how many people ask for them.

How to convert catpart to 3dxml file

Engineering teams export CATIA parts to 3DXML when a reviewer or supplier needs to inspect a model in a compatible viewer without receiving its editable CATIA design. The export can provide a lighter visualization copy while the original part remains available for engineering changes.

What the CATPART format is

.CATPart is CATIA’s native part-document format. It can contain solid or surface geometry, sketches, parameters, and the feature history used to build the part. CATIA users and engineering suppliers use it for design work; assemblies are typically stored separately as .CATProduct documents.

What the 3DXML format is

.3dxml is Dassault Systèmes’ format for sharing and viewing 3D data. Depending on the export settings, a file can contain lightweight tessellated geometry or precise geometry, along with product structure and related data. Tessellated exports are generally suited to review and can be smaller than full CAD data; viewing requires a compatible application.

How to convert the part in CATIA

CATIA is the direct desktop option because it opens CATPART files and supports 3DXML export in configurations that include the required export capability.

  1. Open the .CATPart file in CATIA and check that the intended body or surface is visible.
  2. Choose File → Save As, select 3D XML (*.3dxml) in the file-type list, and set the output filename.
  3. If export settings are offered, choose tessellated or precise geometry as required. For tessellated output, increase the accuracy for smoother curves and edges; higher accuracy usually increases file size.
  4. Save the file and open it in the recipient’s 3DXML-compatible application to verify the geometry and, where relevant, product structure.

If 3DXML is not listed, the option may depend on the CATIA release, installed components, or license. Use a CATIA configuration with 3DXML export support; changing the filename extension does not convert the data. Online conversion is not recommended for confidential or proprietary parts, and CATPART support can vary between services.

Quality and compatibility

3DXML does not preserve the CATIA feature tree and parametric design history as native CATIA features. Tessellated output can appear faceted when exported at low accuracy, while precise geometry may produce larger files and is not supported by every viewer. Keep the original .CATPart when recipients need to edit the design.

CATPART vs 3DXML: format comparison

How the CATPART and 3DXML formats compare on the properties that matter most for this conversion.

Comparison of the CATPART and 3DXML file formats
Property .CATPART CATIA V5 Part File .3DXML 3D XML
Open standard No No
Compression — Both
Typical file size Large Medium
Opens in a web browser No No
Further editing Limited Limited
Metadata support Basic Basic
Plain-text readable No Yes
Best used for Professional production Professional production
Introduced — 2005
Developer Dassault Systèmes Dassault Systèmes
MIME type — application/vnd.3dxml+xml
