Convert CAM to CAMTHTR

Understanding CAM and CAMTHTR file formats

CAM files are typically associated with Gerber CAM (Computer-Aided Manufacturing) data, widely used in PCB (Printed Circuit Board) design and manufacturing. These files contain information about the layout, layers, and components of a PCB, essential for fabrication processes.

CAMTHTR files, on the other hand, are specific to through-hole technology (THT) reports generated by certain PCB design and manufacturing software. These files usually contain detailed information about through-hole components, such as drill sizes, locations, and plating details, which are crucial for the assembly and inspection stages of PCB production.

How to convert CAM to CAMTHTR

Converting a CAM file to a CAMTHTR file typically involves extracting through-hole data from the general CAM file and exporting it in the CAMTHTR format. This process is usually supported by advanced PCB design and CAM software.

Recommended software for CAM to CAMTHTR conversion

The best software for this conversion is Altium Designer or Ucamco UcamX, both of which are industry-standard tools for PCB design and manufacturing. These programs allow you to import CAM files and export specific reports, including through-hole (THT) data, in the required format.

• Altium Designer: Open your CAM file, then use File → Export → Through-Hole Report (CAMTHTR) to generate the CAMTHTR file.
• Ucamco UcamX: Import the CAM file, navigate to the THT report section, and use Export → CAMTHTR to save the file.

Tips for successful conversion

• Ensure your CAM file contains all necessary through-hole data before conversion.
• Check the output CAMTHTR file for accuracy, especially drill sizes and locations.
• Consult your PCB manufacturer for specific CAMTHTR format requirements.
